Logic Elements
The other two LUTs use the data1and data2signals to generate two
possible carry-out signals: one for a carry of 1 and the other for a carry of
0. The carry-in0signal acts as the carry select for the carry-out0
output and carry-in1acts as the carry select for the carry-out1
output. LEs in arithmetic mode can drive out registered and unregistered
versions of the LUT output.
The dynamic arithmetic mode also offers clock enable, counter enable,
synchronous up/down control, synchronous clear, synchronous load,
and dynamic adder/subtractor options. The LAB local interconnect data
inputs generate the counter enable and synchronous up/down control
signals. The synchronous clear and synchronous load options are
LAB-wide signals that affect all registers in the LAB. The Quartus II
software automatically places any registers that are not used by the
counter into other LABs. The addnsubLAB-wide signal controls
whether the LE acts as an adder or subtractor.
