MAX II Architecture
Carry-Select Chain
The carry-select chain provides a very fast carry-select function between
LEs in dynamic arithmetic mode. The carry-select chain uses the
redundant carry calculation to increase the speed of carry functions. The
LE is configured to calculate outputs for a possible carry-in of 0 and
carry-in of 1 in parallel. The carry-in0and carry-in1signals from a
lower-order bit feed forward into the higher-order bit via the parallel
carry chain and feed into both the LUT and the next portion of the carry
chain. Carry-select chains can begin in any LE within an LAB.
The speed advantage of the carry-select chain is in the parallel
pre-computation of carry chains. Since the LAB carry-in selects the
precomputed carry chain, not every LE is in the critical path. Only the
propagation delays between LAB carry-in generation (LE 5 and LE 10) are
now part of the critical path. This feature allows the MAX II architecture
to implement high-speed counters, adders, multipliers, parity functions,
and comparators of arbitrary width.
Figure 2–9 shows the carry-select circuitry in an LAB for a 10-bit full
adder. One portion of the LUT generates the sum of two bits using the
input signals and the appropriate carry-in bit; the sum is routed to the
output of the LE. The register can be bypassed for simple adders or used
for accumulator functions. Another portion of the LUT generates
carry-out bits. An LAB-wide carry-in bit selects which chain is used for
the addition of given inputs. The carry-in signal for each chain,
carry-in0or carry-in1, selects the carry-out to carry forward to the
carry-in signal of the next-higher-order bit. The final carry-out signal is
routed to an LE, where it is fed to local, row, or column interconnects.
