4–8
Chapter 4: Hot Socketing and Power-On Reset in MAX II Devices
Referenced Documents
Referenced Documents
This chapter refereces the following documents:
■
■
DC and Switching Characteristics chapter in the MAX II Device Handbook
Using MAX II Devices in Multi-Voltage Systems chapter in the MAX II Device
Handbook
Document Revision History
Table 4–1 shows the revision history for this chapter.
Table 4–1. Document Revision History
Date and Revision
October 2008,
version2.1
Changes Made
Summary of Changes
■ Updated “MAX II Hot-Socketing Specifications” and “Power-On
—
Reset Circuitry” sections.
■ Updated New Document Format.
December 2007,
version 2.0
■ Updated “Hot Socketing Feature Implementation in MAX II
Updated document with
MAX IIZ information.
Devices” section.
■ Updated “Power-On Reset Circuitry” section.
■ Updated Figure 4–5.
■ Added “Referenced Documents” section.
■ Added document revision history.
December 2006,
version 1.5
—
—
February 2006,
version 1.4
■ Updated “MAX II Hot-Socketing Specifications” section.
■ Updated “AC and DC Specifications” section.
■ Updated “Power-On Reset Circuitry” section.
■ Updated AC and DC specifications on page 4-2.
June 2005,
version 1.3
—
—
December 2004,
version 1.2
■ Added content to Power-Up Characteristics section.
■ Updated Figure 4-5.
June 2004,
version 1.1
■ Corrected Figure 4-2.
—
MAX II Device Handbook
© October 2008 Altera Corporation
ALTERA [ ALTERA CORPORATION ]
