Section II. PCB Layout Guidelines
This section provides information for board layout designers to successfully layout
®
their boards for MAX II devices. It contains the required printed circuit board (PCB)
layout guidelines, device pin tables, and package specifications.
This section includes the following chapters:
■
■
Chapter 7, Package Information
Chapter 8, Using MAX II Devices in Multi-Voltage Systems
Revision History
Refer to each chapter for its own specific revision history. For information about when
each chapter was updated, refer to the Chapter Revision Dates section, which appears
in the complete handbook.
