ABSOLUTE MAXIMUM RATINGS
(VSS1=VSS2=VSS3=VSS4=VSS1A=VSS2A=VSS3A=0V; Note 2, Note 3)
Parameter
Power Supplies:
(Note 4)
Symbol
AVDD
PVDD
SAVDD
DVDD
TVDD2
TVDD3
AVDDA
TVDDA
Min
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
-
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−0.3
−30
−65
-
max
4.0
4.0
4.0
4.0
4.0
4.0
6.0
6.0
6.0
4.0
±10
Units
V
V
V
V
V
V
V
V
V
V
mA
V
V
V
V
V
V
CODEC Analog
PLLBT
10bit SAR ADC
CODEC Digital
CODEC Digital I/O 2
CODEC Digital I/O 3
HP/SPK-Amp Analog
HP/SPK-Amp Digital I/F
Speaker-Amp & Headphone-Amp SVDDA
Charge Pump
PVDDA
IIN
Input Current, Any Pin Except Supplies
Analog Input Voltage 1 (Note 5)
Analog Input Voltage 2 (Note 6)
Analog Input Voltage 3 (Note 7)
Analog Input Voltage 4 (Note 8)
Digital Input Voltage 1 (Note 9)
Digital Input Voltage 2 (Note 10)
Digital Input Voltage 3 (Note 11)
Digital Input Voltage 4 (Note 12)
Ambient Temperature (powered applied)
Storage Temperature
VINA1
VINA2
VINA3
VINA4
VIND1
VIND2
VIND3
VIND4
Ta
AVDD+0.3
SAVDD+0.3
(AVDDA+0.3) or 6.0
6.0
DVDD+0.3
TVDD2+0.3
TVDD3+0.3
(TVDDA+0.3) or 6.0
85
V
V
°C
°C
W
W
Tstg
Pd1
Pd2
150
0.91
1.18
Maximum Power Dissipation Ta=85ºC (Note 14)
(Note 13)
Ta=70ºC (Note 15)
-
Note 2. All voltages with respect to ground.
Note 3. VSS1, VSS2, VSS3, VSS4, VSS1A, VSS2A and VSS3A must be connected to the same analog
ground plane.
Note 4. TVDDA should be connected to DVDD.
Note 5. RIN4/IN4−, LIN4/IN4+, RIN3/IN3−, LIN3/IN3+, RIN2/IN2−, LIN2/IN2+, RIN1/IN1−, LIN1/IN1+ pins
Note 6. SAIN1, SAIN2, SAIN3 pins
Note 7. LIN1A, RIN1A, SPIN pins. The maximum value is smaller value between (AVDDA+0.3)V and 6.0V.
Note 8. VBATIN pin
Note 9. PDN, SCL, SDA, SDTI, LRCK, BICK, MCKI pins
Pull-up resistors at SDA and SCL pins should be connected to (DVDD+0.3)V or less voltage.
Note 10. BICKA, SYNCA, SDTIA pins
Note 11. BICKB, SYNCB, SDTIB pins
Note 12. PDNA, MCKIA pins. The maximum value is smaller value between (AVDDA+0.3)V and 6.0V.
Note 13. In case that the PCB wiring density is 300%. This power is the AK4675 internal dissipation that does not include
power of externally connected speaker and headphone.
Note 14. When Ta=85°C, the HP-Amp power must be under 30mW@16Ω and SPK-Amp power must be 1.0W@8Ω.
Note 15. When Ta=70°C, the HP-Amp power must be under 30mW@16Ω and SPK-Amp power must be 1.6W@8Ω.
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
MS0963-E-00
2008/05
