Agilent HCPL-814
AC Input Phototransistor
Optocoupler
High Density Mounting Type
Data Sheet
Features
AC input response
High input-output isolation voltage
(V =5,000V
)
rms
iso
Description
The HCPL-814 contains a
Ordering Information
Specify Part Number followed by
Option Number (if desired).
Low collector dark current
-7
(I : max. 10 A at V = 20 V)
CEO
CE
phototransistor, optically coupled
to two light emitting diodes
connected inverse parallel. It can
operate directly by AC input
current. It is packaged in a 4-pin
DIP package and available in wide-
lead spacing option and lead bend
SMD option. Input-output isolation
Current transfer ratio
(CTR: min. 20% at I = ±1 mA,
F
HCPL-814-XXXE
V
= 5 V)
CE
Response time
(t : typ. 4 µs at V = 2 V, I = 2 mA,
Lead Free
Option Number
r
CE
C
R =100)
L
Compact dual-in-line package
UL approved
000 = No Options
060 = IEC/EN/DIN EN 60747-5-2
Option
W00 = 0.4" Lead Spacing Option
300 = Lead Bend SMD Option
500 = Tape and Reel Packaging
Option
voltage is 5000 V . Response
rms
time, t , is typically 4 µs and
r
CSA approved
minimum CTR is 20% at input
current of ± 1 mA.
IEC/EN/DIN EN 60747-5-2
approved
Options available:
– Leads with 0.4" (10.16 mm)
spacing(W00)
00A = Rank Mark A
– Leads bend for surface
mounting(300)
– Tape and reel for SMD (500)
– IEC/EN/DIN EN 60747-5-2
approvals(060)
Functional Diagram
1
2
4
3
Applications
Detecting or monitoring AC signals
AC line/digital logic isolation
Programmable logic controllers
AC/DC – input modules
1. ANODE, CATHODE
2. CATHODE, ANODE
3. EMITTER
4. COLLECTOR
CAUTION: It is advised that normal static precautions be taken in handling and assembly of this component to
prevent damage and/or degradation which may be induced by ESD.
