BATTERY PROTECTION IC FOR 2-SERIAL TO 4-SERIAL-CELL PACK (SECONDARY PROTECTION)
Rev.4.4_00
S-8264A/B/C Series
Absolute Maximum Ratings
Table 8
(Ta = 25°C unless otherwise specified)
Item
Symbol
VDS
Applied Pin
VDD
Rating
VSS − 0.3 to VSS + 26
VSS − 0.3 to VDD + 0.3
VSS − 0.3 to VDD + 0.3
450*1
Unit
V
Input voltage between VDD and VSS
Input pin voltage
VIN
SENSE, VC1, VC2, VC3, CTL
CO
V
CO output pin voltage
VCO
V
SNT-8A
Power dissipation
8-Pin TSSOP
mW
mW
°C
°C
PD
⎯
700*1
Operation ambient temperature
Storage temperature
Topr
Tstg
⎯
⎯
−40 to +85
−40 to +125
*1. When mounted on board
[Mounted board]
(1) Board size : 114.3 mm × 76.2 mm × t1.6 mm
(2) Name : JEDEC STANDARD51-7
Caution The absolute maximum ratings are rated values exceeding which the product could suffer physical
damage. These values must therefore not be exceeded under any conditions.
800
8-Pin TSSOP
600
SNT-8A
400
200
0
100
150
50
0
Ambient Temperature (Ta) [°C]
Figure 6 Power Dissipation of Package (When Mounted on Board)
9
