TEA1716T
NXP Semiconductors
Resonant power supply control IC with PFC
Table 5.
Limiting values …continued
In accordance with the Absolute Maximum Rating System (IEC 60134).; All voltages are measured with respect to pin SGND;
Currents are positive when flowing into the IC; The voltage ratings are valid provided other ratings are not violated; Current
ratings are valid provided the maximum power rating is not violated.
Symbol
ESD
Parameter
Conditions
Min
Max
Unit
VESD
electrostatic discharge voltage
Human body model
Pin 12 (SUPHV)
Pin 13,14,15 (HS driver)
other pins
[1]
[1]
[1]
-
-
-
1500
1000
2000
V
V
V
Machine model
All pins
[2]
-
-
200
500
V
V
Charged device model
All pins
[1] Equivalent to discharging a 100 pF capacitor through a 1.5 k series resistor.
[2] Equivalent to discharging a 200 pF capacitor through a 0.75 H coil and a 10 resistor.
9. Thermal characteristics
Table 6.
Symbol
Rth(j-a)
Thermal characteristics
Parameter
Conditions
Typ
90
Unit
K/W
thermal resistance from junction to ambient
In free air; JEDEC single
layer test board
10. Characteristics
Table 7.
Characteristics
Tamb = 25 C; VSUPIC = 20 V; VSUPHV > 40 V; all voltages are measured with respect to SGND; currents are positive when
flowing into the IC; unless otherwise specified.
Symbol
Parameter
Conditions
Min
Typ
Max Unit
High-voltage start-up source (pin SUPHV)
Idism(SUPHV)
disable mode current on pin
SUPHV
Disabled IC state
-
150
-
A
Ired(SUPHV)
Inom(SUPHV)
Itko(SUPHV)
Vdet(SUPHV)
Vrst(SUPHV)
reduced current on pin SUPHV
nominal current on pin SUPHV
takeover current on pin SUPHV
detection voltage on pin SUPHV
reset voltage on pin SUPHV
VSUPIC < Vscp(SUPIC)
-
-
-
-
-
1.1
5.1
7
-
mA
mA
A
V
VSUPIC < Vstart(hvd)(SUPIC)
VSUPIC > Vstart(hvd)(SUPIC)
-
-
-
25
-
VSUPIC < Vrst(SUPIC)
7
V
Low-voltage IC supply (pin SUPIC)
Vstart(hvd)(SUPIC)
Vstart(nohvd)(SUPIC)
Vstart(hys)(SUPIC)
start voltage with high voltage
detected
VSUPHV > Vdet(SUPHV)
-
-
-
20
15
0.3
-
-
-
V
V
V
start voltage with no high voltage
detected
VSUPHV < Vdet(SUPHV) or open
hysteresis of start voltage on pin
SUPIC
TEA1716T
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Objective data sheet
Rev. 1 — 27 January 2012
33 of 46
