ICs for TV
AN5195K-C
■ Electrical Characteristics at Ta = 25°C (continued)
• Design reference data (continued)
Note) The characteristics listed below are theoretical values based on the IC design and are not guaranteed.
Parameter
Symbol
Conditions
Min
Typ Max
Unit
Synchronizing signal processing circuit (continued)
FBP max. allowable input voltage VAFBP
I2C Interface
2.5
5.0
V
Bus free before start
Start condition set-up time
Start condition hold time
Low period SCL, SDA
High period SCL
tBUF
tSU,STA
tHD,STA
tLOW
4.0
4.0
4.0
4.0
4.0
µs
µs
µs
µs
µs
µs
µs
µs
µs
µs
µs
µs
tHIGH
Rise time SCL, SDA
Fall time SCL, SDA
Data set-up time (write)
Data hold time (write)
Acknowledge set-up time
Acknowledge hold time
Stop condition set-up time
DAC
tr
1.0
tf
0.35
tSU, DAT
tHD, DAT
tSU, ACK
tHD, ACK
tSU,STO
0.25
0
3.5
0
4.0
3, 6, 7-bit DAC DNLE
L3,6,7
1LSB = {data (max.) − data (00)}/
7, 63, 127
0.1
0.1
0.1
27
1.0
1.0
1.0
32
1.9
1.9
2.9
37
LSB
Step
8-bit DAC DNLE
8-bit DAC DNLE 80
AFT DAC overlap
L8
1LSB = {data (FF) − data (00)}/255
(except 7F → 80)
LSB
Step
L8-80
∆Step
LSB = {data (FF) − data (00)}/255
(7F → 80)
LSB
Step
Overlap of AFT 8-bit 2-stage
changeover
Step
• Typical conditions when testing
1. Input signal
1) VIF: fP = 38.9 MHz, VIN = 90 dBµ
Video modulation : modulated signal is 10-staircase. Modulation m = 87.5%
IN = 90 dBµ, pin 25 input level approx. 84 dBµ
V
2) SIF: fS = 6.0 MHz, VIN = 90 dBµ, modulated signal fM = 400 MHz, deviation: PAL±50 kHz, NTSC±25 kHz
3) Video: 10-stair-step 0.6 V[p-p] (VBW = 0.42 V[0-p])
4) Chroma: Color bar signal: Burst level 150 mV[p-p]
Rainbow signal: Burst level 150 mV[p-p]
5) Sync. signal: 0.6 V[p-p]
13
