24LC16B
3.6
Device Addressing
4.0
WRITE OPERATION
A control byte is the first byte received following the
start condition from the master device. The control
byte consists of a four bit control code, for the 24LC16B
this is set as 1010 binary for read and write operations.
The next three bits of the control byte are the block
select bits (B2, B1, B0). They are used by the master
device to select which of the eight 256 word blocks of
memory are to be accessed. These bits are in effect
the three most significant bits of the word address. It
should be noted that the protocol limits the size of the
memory to eight blocks of 256 words, therefore the pro-
tocol can support only one 24LC16B per system.
4.1
Byte Write
Following the start condition from the master, the
device code (4 bits), the block address (3 bits), and the
R/W bit which is a logic low is placed onto the bus by
the master transmitter. This indicates to the addressed
slave receiver that a byte with a word address will fol-
low after it has generated an acknowledge bit during
the ninth clock cycle. Therefore the next byte transmit-
ted by the master is the word address and will be writ-
ten into the address pointer of the 24LC16B. After
receiving another acknowledge signal from the
24LC16B the master device will transmit the data word
to be written into the addressed memory location. The
24LC16B acknowledges again and the master gener-
ates a stop condition. This initiates the internal write
cycle, and during this time the 24LC16B will not gener-
ate acknowledge signals (Figure 4-1).
The last bit of the control byte defines the operation to
be performed. When set to one a read operation is
selected, when set to zero a write operation is selected.
Following the start condition, the 24LC16B monitors
the SDA bus checking the device type identifier being
transmitted, upon a 1010 code the slave device outputs
an acknowledge signal on the SDA line. Depending on
the state of the R/W bit, the 24LC16B will select a read
or write operation.
4.2
Page Write
The write control byte, word address and the first data
byte are transmitted to the 24LC16B in the same way
as in a byte write. But instead of generating a stop con-
dition the master transmits up to 16 data bytes to the
24LC16B which are temporarily stored in the on-chip
page buffer and will be written into the memory after the
master has transmitted a stop condition. After the
receipt of each word, the four lower order address
pointer bits are internally incremented by one. The
higher order seven bits of the word address remains
constant. If the master should transmit more than 16
words prior to generating the stop condition, the
address counter will roll over and the previously
received data will be overwritten. As with the byte write
operation, once the stop condition is received an inter-
nal write cycle will begin (Figure 4-2).
Control
Code
Operation
Block Select
R/W
Read
Write
1010
1010
Block Address
Block Address
1
0
FIGURE 3-2: CONTROL BYTE
ALLOCATION
START
READ/WRITE
SLAVE ADDRESS
R/W
A
1
0
1
0
X
X
X
X = Don’t care
FIGURE 4-1: BYTE WRITE
S
S
T
BUS ACTIVITY
MASTER
CONTROL
BYTE
WORD
ADDRESS
T
A
R
T
DATA
O
P
SDA LINE
S
P
A
C
K
A
C
K
A
C
K
BUS ACTIVITY
FIGURE 4-2: PAGE WRITE
S
S
T
O
P
T
BUS ACTIVITY
MASTER
A
R
T
CONTROL
BYTE
WORD
ADDRESS (n)
DATA n
DATA n + 1
DATA n + 15
SDA LINE
S
P
A
C
K
A
C
K
A
C
K
A
C
K
A
C
K
BUS ACTIVITY
1998 Microchip Technology Inc.
DS20070H-page 5
