Direct Solder for Semi-Rigid .047”, .085” and .141” Cable
Panel Mount Solder Jack - 4 hole Square Flange - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA6581A2-3GT50G-11-50
SMA6581A1-3GT50G-10-50
SMA6581A3-3GT50G-13-50
11
10
13
Gold
Gold
Gold
Teflon
Teflon
Teflon
50
50
50
N/A
N/A
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction B - page 210
Assembly Instruction C - page 211
Panel Mount Solder Jack - 2 hole Square Flange - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA6581B2-3GT50G-11-50
SMA6581B1-3GT50G-10-50
SMA6581B3-3GT50G-13-50
11
10
13
Gold
Gold
Gold
Teflon
Teflon
Teflon
50
50
50
N/A
N/A
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction B - page 210
Assembly Instruction C - page 21q
29
For Reversed Polarized connectors contact local Amphenol Sales Branch.
