Direct Solder for Semi-Rigid .047”, .085” and .141” Cable
Straight Solder Plug - With Contact and Torque Nut - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
SMA1181A1-004-3GT50G-11-50 11
Stainless Steel Nut
Gold
Teflon
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction B - page 210
Right Angle Solder Plug DC - 12.4 GHZ - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA1182A2-3GT50G-10-50
SMA1182Z2-3GT50G-11-50
Stainless Steel Nut
10
11
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
SMA1182A2-3GT50G-11-50
SMA1182A2-3GT50G-13-50
11
13
Gold
Gold
Teflon
Teflon
50
50
N/A
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction D - page 212
Straight Solder Jack - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA6181A1-3GT50G-10-50
SMA6181A2-3GT50G-11-50
SMA6181A2-3GT50G-13-50
10
11
13
Gold
Gold
Gold
Teflon
Teflon
Teflon
50
50
50
N/A
N/A
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction B - page 210
Assembly Instruction C - page 211
Bulkhead Feedthrough Solder Jack - O-Ring seal - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA6481A1-3GT50G-10-50
SMA6481A2-3GT50G-11-50
SMA6481A2-3GT50G-13-50
10
11
13
Gold
Gold
Gold
Teflon
Teflon
Teflon
50
50
50
N/A
N/A
N/A
Cable: .047” Cable, A = 1.24 mm [.049”] min,
.085” Cable, A = 2.2 mm [.087”] min,
.141” Cable, A = 3.6 mm [.142”] min,
Assembly Instruction B - page 210
Assembly Instruction C - page 211
28
For Reversed Polarized connectors contact local Amphenol Sales Branch.
