SMA Coaxial Connectors
All connectors listed, unless otherwise noted, are Commercial Grade construction, gold-plated
brass bodies, with 50µ” gold contacts.
All insulators are Teflon.
All other parameters are equal to Mil Standard construction.
Mil Standard connectors, i.e. Stainless Steel body, available upon request as per material specifi-
cations listed in Material section on preceding page.
All dimensions are in millimeters and [inches].
Plug Direct Solder for Semi-Rigid .047", .085" and .141" Cable
Straight Solder Plug - Cable Inner Conductor Center Contact - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
N/A
Imp.
50
SMA1181K1-3G-10-50
10
Gold
N/A
Assembly Instruction A - page 209
Straight Solder Plug - With Contact - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
SMA1181A2-3GT50G-11-50
SMA1181A1-3GT50G-10-50
SMA1181K1-S/P-10-50
Stainless Steel
11
10
10
Gold
Gold
Gold
Teflon
Teflon
Teflon
50
50
50
N/A
N/A
N/A
SMA1181A2-3GT50G-13-50
13
Gold
Teflon
50
N/A
Assembly Instruction B - page 210
Assembly Instruction C - page 211
27
For Reversed Polarized connectors contact local Amphenol Sales Branch.
