TNC Coaxial Connectors
All connector bodies, unless otherwise noted, are nickel plated. Center contacts are 3µ” gold plated.
Insulators are Delrin, unless otherwise noted.
Silver plating and Teflon insulators are available on virtually all TNC connectors. Please contact
Amphenol for samples and quotes.
All dimensions in millimeters and [inches].
Plug Crimp Attachment for Flexible Cable
Straight Crimp plug - Single crimp - Standard Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
T1111K1-ND3G-1-50
T1111K1-ND3G-3-75
01
03
Nickel
Nickel
Delrin
Delrin
50
75
5
5
Remark: Only for solid center conductor cable
Assembly Instruction J - page 218
Assembly Instruction J - page 218
Assembly Instruction J - page 218
Straight Crimp Plug - Standard Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
T1121A1-ND3G-1-50
T1121A1-ND3G-1A-50
T1121A1-ND3G-1B-50
T1121AA-ND3G-3-50
T1121AA-ND3G-3-75
T1121A1-ND3G-3A-75
T1121A6-NT3G-7-50
T1121A6-NT3G-7A-50
T1121A1-NT3G-7B-50
T1121A6-NT3G-7C-50
T1121A1-ND3G-8-75
T1121A1-ND3G-15-75
T1121A1-019-NT3G-17-50
01
01A
01B
03
03
03A
07
07A
07B
07C
08
15
17
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Nickel
Delrin
Delrin
Delrin
Delrin
Delrin
Delrin
Teflon
Teflon
Teflon
Teflon
Delrin
Delrin
Teflon
50
50
50
50
75
75
50
50
50
50
75
75
50
3
3 or 4
3 or 4
4
4
4
4 + 5
4 + 6
4
6
5
5
.610 hex
Straight Crimp Plug - Plenum Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
50
T1121C1-001-ND3G-2-50
02
Nickel
Delrin
3 or 4
97
For Reversed Polarized connectors contact local Amphenol Sales Branch.
