Right Angle Plug Crimp Attachment for Flexible Cable and Direct Solder for Semi-Rigid Cable
Right Angle Solder Plug - Semi-Rigid Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
T1182A1-N/3GT3G-11-50
T1182A1-N/3GT3G-10-50
11
10
Nickel/Gold Teflon
Nickel/Gold Teflon
50
50
N/A
N/A
Assembly Instruction F - page 214
Right Angle Crimp/Crimp Plug - Miniature Cable
Cable
Group
Crimp
Tool
P.N.
Plt.
Ins.
Imp.
T1122E1-ND3G-5-50
T1122E1-ND3G-6-75
T1122E1-ND3G-5A-50
05
06
05A
Nickel
Nickel
Nickel
Delrin
Delrin
Delrin
50
75
50
9
9
9
Remark: With teflon sleeve, Hex. crimp size .178”, Crimp/Crimp Type
Assembly Instruction S - page 227
101
For Reversed Polarized connectors contact local Amphenol Sales Branch.
