ST90158 - GENERAL DESCRIPTION
1 GENERAL DESCRIPTION
1.1 INTRODUCTION
1.1.2 Power Saving Modes
To optimize performance versus power consump-
tion, a range of operating modes can be dynami-
cally selected.
The ST90158 and ST90135 microcontrollers are
developed and manufactured by STMicroelectron-
ics using a proprietary n-well CMOS process.
Their performance derives from the use of a flexi-
ble 256-register programming model for ultra-fast
context switching and real-time event response.
The intelligent on-chip peripherals offload the ST9
core from I/O and data management processing
tasks allowing critical application tasks to get the
maximum use of core resources. The new-gener-
ation ST9 MCU devices now also support low
power consumption and low voltage operation for
power-efficient and low-cost embedded systems.
Run Mode. This is the full speed execution mode
with CPU and peripherals running at the maximum
clock speed delivered by the Phase Locked Loop
(PLL) of the Clock Control Unit (CCU).
Slow Mode. Power consumption can be signifi-
cantly reduced by running the CPU and the periph-
erals at reduced clock speed using the CPU Pres-
caler and CCU Clock Divider (PLL not used) or by
using the CK_AF external clock.
Wait For Interrupt Mode. The Wait For Interrupt
(WFI) instruction suspends program execution un-
til an interrupt request is acknowledged. During
WFI, the CPU clock is halted while the peripheral
and interrupt controller keep running at a frequen-
cy programmable via the CCU.
1.1.1 ST9 Core
The advanced Core consists of the Central
Processing Unit (CPU), the Register File, the Inter-
rupt and DMA controller, and the Memory Man-
agement Unit (MMU). The MMU allows address-
ing of up to 4 Megabytes of program and data
mapped into a single linear space.
Halt Mode. When executing the HALT instruction,
and if the Watchdog is not enabled, the CPU and
its peripherals stop operating and the status of the
machine remains frozen (the clock is also
stopped). A reset is necessary to exit from Halt
mode.
Four independent buses are controlled by the
Core: a 16-bit memory bus, an 8-bit register data
bus, an 8-bit register address bus and a 6-bit inter-
rupt/DMA bus which connects the interrupt and
DMA controllers in the on-chip peripherals with the
core.
1.1.3 System Clock
A programmable PLL Clock Generator allows
standard 3 to 5 MHz crystals to be used to obtain a
large range of internal frequencies up to 16 MHz or
24 MHz, depending on device.
This multiple bus architecture makes the ST9 fam-
ily devices highly efficient for accessing on and off-
chip memory and fast exchange of data with the
on-chip peripherals.
1.1.4 I/O Ports
The general-purpose registers can be used as ac-
cumulators, index registers, or address pointers.
Adjacent register pairs make up 16-bit registers for
addressing or 16-bit processing. Although the ST9
has an 8-bit ALU, the chip handles 16-bit opera-
tions, including arithmetic, loads/stores, and mem-
ory/register and memory/memory exchanges.
The I/O lines are grouped into up to nine 8-bit I/O
Ports and can be configured on a bit basis to pro-
vide timing, status signals, an address/data bus for
interfacing to external memory, timer inputs and
outputs, analog inputs, external interrupts and se-
rial or parallel I/O.
6/199
