ST6200C/ST6201C/ST6203C
1 INTRODUCTION
The ST6200C, 01C and 03C devices are low cost
members of the ST62xx 8-bit HCMOS family of mi-
crocontrollers, which is targeted at low to medium
complexity applications. All ST62xx devices are
based on a building block approach: a common
core is surrounded by a number of on-chip periph-
erals.
mable option bytes of the OTP/EPROM versions
in the ROM option list (See Section 12.6 on page
95).
The ST62P00C, P01C and P03C are the Factory
Advanced Service Technique ROM (FASTROM)
versions of ST62T00C, T01 and T03C OTP devic-
es.
The ST62E01C is the erasable EPROM version of
the ST62T00C, T01 and T03C devices, which may
be used during the development phase for the
ST62T00C, T01 and T03C target devices, as well
as the respective ST6200C, 01C and 03C ROM
devices.
They offer the same functionality as OTP devices,
but they do not have to be programmed by the
customer (See Section 12 on page 89).
These compact low-cost devices feature a Timer
comprising an 8-bit counter with a 7-bit program-
mable prescaler, an 8-bit A/D Converter with 4 an-
alog inputs (depending on device, see device
summary on page 1) and a Digital Watchdog tim-
er, making them well suited for a wide range of au-
tomotive, appliance and industrial applications.
OTP and EPROM devices are functionally identi-
cal. OTP devices offer all the advantages of user
programmability at low cost, which make them the
ideal choice in a wide range of applications where
frequent code changes, multiple code versions or
last minute programmability are required.
For easy reference, all parametric data are located
in Section 11 on page 61.
The ROM based versions offer the same function-
ality, selecting the options defined in the program-
Figure 1. Block Diagram
8-BIT *
A/D CONVERTER
TEST
TEST/V
PP
PA1..PA3 (20mA Sink)
PORT A
NMI
INTERRUPTS
PB0..PB1
PORT B
PB3, PB5..PB7 / Ain*
DATA ROM
USER
PROGRAM
:
SELECTABLE
MEMORY
(1K or 2K Bytes)
TIMER
DATA RAM
64 Bytes
WATCHDOG
TIMER
PC
STACK LEVEL 1
STACK LEVEL 2
STACK LEVEL 3
STACK LEVEL 4
STACK LEVEL 5
STACK LEVEL 6
8-BIT CORE
POWER
RESET
RESET
OSCILLATOR
SUPPLY
V
V
OSCin OSCout
DD SS
* Depending on device. See device summary on page 1.
6/104
