RTL8211C & RTL8211CL
Datasheet
1. General Description
The Realtek RTL8211C(L) is a highly integrated Ethernet transceiver that complies with 10Base-T,
100Base-TX, and 1000Base-T IEEE 802.3 standards. It provides all the necessary physical layer functions
to transmit and receive Ethernet packets over CAT 5 UTP cable or CAT 3 UTP (10Mbps only) cable.
The RTL8211C(L) uses state-of-the-art DSP technology and an Analog Front End (AFE) to enable
high-speed data transmission and reception over UTP cable. Functions such as Crossover Detection &
Auto-Correction, polarity correction, adaptive equalization, cross-talk cancellation, echo cancellation,
timing recovery, and error correction are implemented in the RTL8211C(L) to provide robust transmission
and reception capabilities at 10Mbps, 100Mbps, or 1000Mbps.
Data transfer between MAC and PHY is via the Reduced Gigabit Media Independent Interface (RGMII) for
1000Base-T, 10Base-T, and 100Base-TX.
