10.4. DC Characteristics
Table 45. DC Characteristics
Symbol
Parameter
Conditions
Minimum
Typical
3.3
Maximum
3.63
Units
V
VDD33,
AVDD33
3.3V Supply Voltage
-
-
-
2.97
RGMII I/O 2.5V RGMII Supply Voltage
2.37
2.5
2.62
V
DVDD10,
1.05V Supply Voltage
AVDD10
0.95
1.05
1.09
V
Voh (3.3V) Minimum High Level Output Voltage
Voh (2.5V) Minimum High Level Output Voltage
-
-
-
-
-
-
0.9*VDD33
-
-
-
-
-
-
VDD33
VDD25
0.1*VDD33
0.1*VDD25
-
V
V
V
V
V
V
0.9*VDD25
Vol (3.3V)
Vol (2.5V)
Vih
Maximum Low Level Output Voltage
Maximum Low Level Output Voltage
Minimum High Level Input Voltage
Maximum Low Level Input Voltage
0
0
1.8
-
Vil
0.9
Vin=VDD33
or GND
Iin
Input Current
0
-
0.5
µA
10.5. AC Characteristics
10.5.1. MDC/MDIO Timing
MDC/MDIO Timing – Management Port
tMCC
tMCH
Vih(min)
Vil(max)
MDC
tMCL
tMSU
tMRV
tMHT
Vih(min)
Vil(max)
MDIO
Figure 19. MDC/MDIO Management Timing Parameters
