LXT350 — T1/E1 Short Haul Transceiver with Crystal-less Jitter Attenuation
Table 3. LXT350 Signal Descriptions
Pin #
Symbol
I/O1
Description
PLCC
QFP
Master Clock. External, independent clock signal required to generate internal
clocks. For T1 applications, a 1.544 MHz clock is required; for E1, a 2.048 MHz
clock. MCLK must be jitter-free and have an accuracy better than ± 50 ppm
with a typical duty cycle of 50%. Upon Loss of Signal (LOS), RCLK is derived
from MCLK.
1
39
MCLK
TCLK
DI
DI
Transmit Clock. For T1 applications, a 1.544 MHz clock is required; for E1, a
2.048 MHz clock. The transceiver samples TPOS and TNEG on the falling
edge of TCLK (or MCLK, if TCLK is not present).
2
41
BIPOLAR MODES:
Transmit – Positive and Negative. TPOS and TNEG are the positive and
negative sides of a bipolar input pair. Data to be transmitted onto the twisted-
pair line is input at these pins. TPOS/TNEG are sampled on the falling edge of
TCLK (or MCLK, if TCLK is not present).
UNIPOLAR MODES:
Transmit Data. TDATA carries unipolar data to be transmitted onto the twisted-
pair line and is sampled on the falling edge of TCLK.
3
4
42
43
DI
DI
TPOS / TDATA /
INSLER
Transmit Insert Logic Error. In QRSS mode, a Low-to-High transition on
INSLER inserts a logic error into the transmitted QRSS data pattern. The
inserted error follows the data flow of the active loopback mode. The LXT350
samples this pin on the falling edge of TCLK (or MCLK, if TCLK is not present).
TNEG / INSBPV
Transmit Insert Bipolar Violation. INSBPV is sampled on the falling edge of
TCLK (or MCLK, if TCLK is not present) to control Bipolar Violation (BPV)
insertions in the transmit data stream. A Low-to-High transition is required to
insert each BPV. In QRSS mode, the BPV is inserted into the transmitted
QRSS pattern.
Mode Select. Connect Low to select Hardware mode. Connect High to select
Host mode. See Table 5 on page 19 for a complete list of operating modes.
5
2
MODE
DI
BIPOLAR MODES:
Receive – Negative and Positive. RPOS and RNEG are the positive and
negative sides of a bipolar output pair. Data recovered from the line interface is
output on these pins. A signal on RNEG corresponds to receipt of a negative
pulse on RTIP/RRING. A signal on RPOS corresponds to receipt of a positive
pulse on RTIP/RRING. RNEG/RPOS are Non-Return-to-Zero (NRZ). In
Hardware mode, RPOS/RNEG are stable and valid on the rising edge of
RCLK. In Host mode, the CLKE pin selects the RCLK clock edge when RPOS
/RNEG are stable and valid as described in Table 4 on page 18.
6
7
3
4
RNEG / BPV
DO
DO
RPOS / RDATA
UNIPOLAR MODES:
Receive Bipolar Violation. BPV goes High to indicate detection of a bipolar
violation from the line. This is an NRZ output and is valid on the rising edge of
RCLK.
Receive Data. RDATA is the unipolar NRZ output of data recovered from the
line interface. In Hardware mode, RDATA is stable and valid on the rising
edge of RCLK. In Host mode, the CLKE pin selects the RCLK clock edge
when RDATA is stable and valid as described in Table 4 on page 18.
Receive Recovered Clock. The clock recovered from the line input signal is
output on this pin. Under LOS conditions, there is a smooth transition from the
RCLK signal (derived from the recovered data) to the MCLK signal, which
appears at the RCLK pin.
8
5
RCLK
DO
1. DI = Digital Input; DO = Digital Output; DI/O = Digital Input/Output; AI = Analog Input; AO = Analog Output.
2. Midrange is a voltage level such that 2.3 V ≤ Midrange ≤ 2.7 V. Midrange may also be established by letting the pin float.
10
Datasheet
