a-Si TFT LCD Single Chip Driver
240RGBx320 Resolution and 262K color
ILI9325
The following table shows specifications of external elements connected to the ILI9325’s power supply circuit.
Items
Recommended Specification
Pin connection
VREG1OUT, VCI1, VDDD, VCL, VCOMH,
VCOML, C11+/-, C12+/-, C13+/-,
DDVDH, C21+/-, C22+/-
6.3V
Capacity
1 µF (B characteristics)
10V
25V
VGH, VGL
Schottky diode
VF<0.4V/20mA at 25°C, VR ≥30V
(GND – VGL), (Vci – VGH), (Vci – DDVDH)
(Recommended diode: HSC226)
