4. Input Interface Levels
The CMOS-N5 Family gate array family has the following four types of interface levels.
(1) CMOS level input
(2) TTL level input
(3) CMOS Schmitt input
(4) TTL Schmitt input
5. Output Drive Capability
The following levels are available for output drive capability.
CMOS level output (Six types) : (3.0 mA, 6.0 mA, 9.0 mA, 12.0 mA, 18.0 mA and 24.0 mA)
6. Multifunction Buffers
6.1 Buffers with Pull-up/Pull-down Resistors
The CMOS-N5 Family have input/output/bidirectional buffers with the following on-chip pull-up/pull-down
resistors. Select one suitable for the specific application.
(1) Pull-up resistor
(2) Pull-down resistor : 50 kΩ (TYP.)
(3) Pull-up resistor : 5 kΩ (TYP.)
: 50 kΩ (TYP.)
6.2 Low Slew-Rate Buffers
The CMOS-N5 Family have special buffers that satisfy low noise requirement by fixing slew-rate low. These
are called low slew-rate buffers. In this library, these buffers are described with a word “Low-noise” at their
function description.
