series
OPEN STYLE, METAL COVER/SHIELD REED RELAY
RRN
The RRN Series is a open construction, one piece nylon bobbin,
P.C. terminal assembly with a metal Cover/Shield (3 sided).
* WIRING DIAGRAMS
(Top View)
RRN1A
.740 Wide
RRN2A
.958 Wide
RRN3A
1.188 Wide
RRN2B
1.188 Wide
RRN1C
.740 Wide
RRN1B
.958 Wide
+
+
RRN3C
1.418 Wide
RRN2C
1.418 Wide
RRN4A
1.418 Wide
OUTLINE DIMENSIONS
Shown in Inchs and (Millimeters)
* See Wiring Diagrams for Width.
*
2.50 Max.
(63.5)
.64 Max.
(16.2)
1.90 Max.
(48.2)
.38
0.156
(3.9)
0.10
(2.54)
(9.6)
.200
(5.0)
.800
(20.3)
.500
(12.7)
2 POLE CASE SIZE
Terminals on 0.2 Inch grid. The 1 and 3
pole units have the middle terminals on
the center line.
WEBSITE: www.magnecraft.com - EMAIL:info@magnecraft.com - FAX ON DEMAND 1-800/891-2957 - DOCUMENT 100
PAGE 87
