SERIES
P.C. TERMINAL, MOLDED MINIATURE REED RELAY
MR-Y
The MR-Y Series epoxy molded miniature reed relay has terminal pins on each end and
spaced 1 inch apart. It is available with two grid spacings - 0.1 inch or 0.15 inch. Available
contacts range from SPST-NO to DPDT configurations. As an option, Mercury reeds are
available in limited contact configurations. Lower power coils are also available in addition to
optional diode across the coil and electrostatic shielding.
WIRING DIAGRAM
Top View
+
+
+
+
*
SPST-NO
MR30Y1A
MR35Y1A
SPST-NC
MR30Y1B
MR35Y1B
*
*
DPDT
MR30Y2C
MR35Y2C
+
*
SPDT
MR30Y1C
MR35Y1C
DPST-NO
MR30Y2A
MR35Y2A
OUTLINE DIMENSIONS
Dimensions shown are in Inches and (Millimeter)
.950
(24.1)
.550
(13.9)
.400
(10.1)
.312
(7.9)
.130
(3.3)
.010
(.254)
.020 Typ.
(.508)
.045 Typ.
(1.14)
DIM. "A" SEE CHART
DIM. "B" SEE CHART
DIMENSION CHART
Position Reference
.062 R x .032 Deep
DIM "A"
DIM."A"
DIM "B"
DIM."B"
0.100 0.10 Grid
0.150 0.15 Grid
0.200 0.10 Grid
0.300 0.15 Grid
1.00
(25.4)
PAGE 83
