CLASS
OPEN STYLE, METAL COVER/SHIELD REED RELAY
102
102MPCX/RMPCX
SPST-N.O.
METAL SHIELD ON THREE SIDES.
0.2 GRID SPACING.
OUTLINE DIMENSIONS
Dimensions shown are in Inch and (Millimeter)
.760 Max.
(19.3)
2.67 Max.
(16.5)
.65 Max.
(16.5)
.38
.18 Max.
(4.5)
1.90 Max.
(48.2)
0.16
(4.0)
(9.6)
.200
(5.0)
.400
(10.1)
1 POLE CASE SIZE
GENERAL SPECIFICATIONS 102
102
102R
RELAY CLASS
102
102R
RELAY CLASS
Contact Resistance Initial:
Dielectric Withstanding voltage:
Across Open Contacts:
Between all other mutually
Insulated points.:
Capacitance, Non Shield, N.O.:
Insulation Resistance:
Coil Dissipation (mW)
Mounting Position:
Shock (Non operation):
Vibration:
1.0 pf
1.5 pf
200
200
109 at 100 VDC
50 to 1.5W
Any
30 G's 11mS ± 1 mS 1/2 Sign
10 G"s 10 to 1000 Hz
-40˚C to + 85˚C
600
700 VDC 450 VDC
1000 VDC
Operate Time (mS):
Bounce Time No Diode (mS):
1.0
2
2.0
2
Temperature Range (operating):
Life At rated load:
200 Million
20 Million
@1A, 115V rms
COIL MEASURED AT 25˚C
MAX. CONTACT RATING
CIRCUIT
DIAGRAM
(TOP VIEW)
NOMINAL
RESIS-
NOMINAL
POWER
(mW)
NOMINAL
INPUT
VOLTAGE
MINIMUM
DROPOUT
MAXIMUM
PULL-IN
SWITCHING
CURRENT &
VOLTAGE
PART
NUMBERS
SWITCHING
LOAD
CARRY
CURRENT
TANCE
(OHMS)
SPST-N.O. 1 AMP
W102MPCX-7
12
24
250 Ω
9.0
1.0
2.0
15VA
580 mW
1 AMP
250VDC
2 AMPS
W102MPCX-8
1000 Ω
18.0
SPST-N.O. 3 AMP
1.0
2.0
250 Ω
W102RMPCX-2
12
24
9.0
3 AMP
250VDC
580 mW
100VA
3.5 AMPS
1000 Ω
W102RMPCX-3
18.0
PART NUMBERS SHOWN AVAILABLE THRU STOCKING DISTRIBUTION
WEBSITE: www.magnecraft.com - EMAIL:info@magnecraft.com - FAX ON DEMAND 1-800/891-2957 - DOCUMENT 100
PAGE 89
