SERIES
GENERAL PURPOSE 4 POLE 10 AMP PLUG-IN RELAY
284
The series 284 relay is a extension of the Class 388/283
style relay except it provides for 4PDT contacts, any
one set of contacts capable of switching 10 Amps (total
load of 30 Amps at 120 VAC and 20 Amps at 240 VAC).
This relay has the 3 way terminal design for greater flexibility
in making connections. The 0.187 Spade terminals can be
soldered, plugged into sockets or connected using 3/16"
Q.C. Female connectors.
UL Recognized
File No. E13224
OUTLINE DIMENSIONS
Dimensions shown are in INCHES and (millimeters)
MANUAL PUSH
BUTTON
0.218
(5.53)
1.50
ACTUATOR (OPTIONAL)
1.93
(49.0)
(38.1)
1.31
(33.3)
1.87
(47.4)
0.020 Typ.
(.508)
0.187 Typ.
(4.74)
0.28
(7.11)
Struthers-Dunn
WIRING DIAGRAM
(VIEWED FROM TERMINAL END)
ORDERING CODE
Typical Type No.
284 XDX C GLM -240A
Series
1
5
2
6
3
7
4
8
284 3 way terminals
10 Amp, 4 pole
Contact Arrangements
XDX (4PDT)
11
12
14
9
10
Construction Style
13
Open, with tapped 6-32 hole - NO CODE
Open, with 6-32 Stud - CODE S
Enclosed, 3 way terminals - CODE C
Options
10 Amp contacts Standard - NO CODE
Gold diffused contacts - CODE G
Indicator Lamp - CODE L
Manual Actuator - CODE M
Printed Circuit Terminals - CODE T
5 Amp contacts (Silver) - CODE Y
Coil Voltage
AC: 6, 12, 24, 48, 120, 240 (Add "A")
DC: 6, 12, 24, 48, 115, 125 (Add "D")
SEE NEXT PAGE FOR RATINGS & SPECIFICATIONS
PAGE 19
