SERIES
OVER/UNDER VOLTAGE SENSING, 10 AMP, 2-4 POLE
349
SERIES 349
FREQUENCY 50 to 400 Hz
PULL-IN ADJUSTABLE
BETWEEN 85 to 135 VAC
10 AMP CONTACTS
OUTLINE DIMENSIONS
Dimensions shown are in INCHES and (millimeters)
Differential 4.0 volts ±
1 Volt nonadjustable
.313
(7.95)
1
6
The Series 349 Under/Over Voltage Sensing
Relay incorporates a Series 219 relay and an
Electronic Module. Pull-in Voltage is adjustable
between 85 and 135 VAC for frequencies from
50 to 400 Hz. Models available for Single and
Three Phase sensing with differential (between
pull-in and Dropout) Adjustable from 2 to 14 Volts
by external fixed or adjustable resistor. Single
Phase relays are also available with standard 3
volt fixed differential and other fixed values up to
14 volts, on special order.
12
7
3.75
(95.2)
SINGLE PHASE -349BBXP
RESISTOR
6
4.56
(115.8)
1
12
7
-349ABXP
SINGLE PHASE
349 ABXP & XBXP Style the
Differential Adjustment is
Externally Adjustable from 3
to 14 Volts.
A
1
B
C
N
RESISTOR
6
1.468
(37.2)
6
7
1
SENSING MODULE
CONTACT LOAD SPECIFICATIONS
12
Inductive
Make
Carry Resistive
Voltage
12
24 VDC
120 VAC
240 VAC
28 VDC
125 VDC
30A
30A
30A
30A
30A
10A
10A
10A
10A
10A
10A
10A
5A
10A
0.5A
10A
3A
7
2.625
(66.6)
THREE PHASE
-349XBXP
1A
3A
0.1A
For Versions with suffix "69"
Permanent Magnet Blowouts
Struthers-Dunn
349 BBX P L33- 85-135A
125 VDC (SM) 30A
10A
10A
10A
10A
1.5A
4A
0.5A
1.5A
150mA
0.5A
125 VDC (DM)
250 VDC (SM)
30A
30A
Typical Part Number
0.5A
1.5A
250 VDC (DM) 30A
Series
349 Sensor -Plug-in, Over/Under
Voltage Relay, 10A, 2 -4 poles
GENERAL SPECIFICATIONS SERIES 349 SENSOR
INPUT
Contact Arrangement & Function
BBX - 2 Form A & 2 Form C, (Single Phase)
4V ± 1V Fixed.
Adjustment 85 to 135 VAC, 50 to 400 Hz
De-energized -15 mA, Energized - 50 mA
Module Voltage:
AC Current Drain:
ABX - 1 Form A & 2 Form C, (Single Phase)
Ext. Adjustment, 3 to 14V
XBX - 2 Form C, (3 Phase)
CONTACTS
Contact Material:
Silver Cadmium Oxide. - Gold Diffused
External Adjustment, 3 to 14V
OPERATIONAL CHARACTERISTICS
Operate time:
25 Milliseconds
25 Milliseconds
Release Time:
Standard Features
Plug-in With Polycarbonate Cover - Code P
INSULATION CHARACTERISTICS
Dielectric Strength
Options
Indicator Lamp- Code L
Manual Actuator - Code M
Bifurcated Contacts (5 Amps max) - Code 33
Permanent Magnet, Blowout Code 69
500 V rms
Across Open Contacts:
All Mutually Insulated Points:
Insulation Resistance
1500 V rms
1000 Megohms min. @ 500VDC.
ENVIRONMENTAL CAPABILITIES
-10˚C to +60˚C @ Rated Operation.
Ambient Temperature Rating:
LIFE EXPECTANCY
Mechanical:
Operating Voltage
20 Million Operations no load
100,000 Operations @ Rated Load.
500,000 @ 1/2 Rated Load.
AC; 85 to 135 (Add "A" )
Electrical:
DC; Consult Factory
Note: For non-Standard Differential Consult Factory
MISCELLANEOUS
Enclosure:
Clear polycarbonate
10 oz. (284 g)
SEE SECTION 10
FOR
MATING SOCKETS
Weight:
PAGE 133
