C L A S S
ADJUSTABLE VOLTAGE SENSING RELAY
236
OUTLINE DIMENSIONS
Dimensions are Shown In Inches and (Millimeters)
WIRING DIAGRAMS
VIEWED FROM PIN END
2.90 Max.
(73.8)
.312
(7.9)
1.53
(38.8)
1
4
2
5
3
6
1
4
2
5
3
6
1.40
(35.7)
FIGURE "B"
7
9
8
7
8
9
A
B
B
A
INPUT
SQUARE BASE
Continuous Voltage
must be supplied to Input.
Screw Driver Adjustable with
Graduated scale.
OUTLINE DIMENSIONS
Dimensions are Shown In Inches and (Millimeters)
.
562 (14.2)
L.E.D
WIRING DIAGRAMS
VIEWED FROM PIN END
2.93
(74.4)
FIGURE "A"
▼
▲
▼
▲
4
1
5
8
3
2
6
7
-
+
INPUT
2.37
(60.3)
8 PIN OCTAL
Continuous Voltage
7
6
must be supplied to Input.
5
4
8
1
1.75
(44.4)
3
2
VOLTAGE
PULL-IN
RANGE
NOMINAL
FIG.
VOLTAGE
DROP-OUT
RANGE
CROSS REFERENCE
TO
POTTER & BRUMFIELD
PART NUMBERS
INPUT
VOLTAGE
75% to 95%
of Pickup
Voltage
120 VAC
208/220 240 VAC
480 VAC
W236ACX-1
W236ACX-2
W236ACX-4
B
B
B
90 to 138 VAC
180 to 276 VAC
360 to 552 VAC
-
-
-
Setting
120 VAC
24 VAC
24 VDC
90 to 138 VAC
18 to 28VAC
18 to 28 VDC
W236ACPX-1
W236ACPX-4
W236CPX-1
A
A
A
92 to 140 VAC
20 to 30 VAC
20 to 30 VDC
CSJ-38-70010
CSJ-38-30010
CSL-38-30010
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
PAGE 135
