C L A S S
PROGRAMMABLE TIME DELAY RELAY
211PROGX
CLASS 211 PROGRAMMABLE TIME DELAY RELAY
± 0.1 % REPEATABILITY
3 INPUT VOLTAGE RANGES
✝ 4 PROGRAMMABLE FUNCTIONS
SEE SECTION 10
FOR
MATING SOCKETS
✝ 62 PROGRAMMABLE TIMING RANGES
RATED AT 10 AMPS, DPDT CONTACTS
✝ SELECTION OF TIMING RANGE AND TIMING
FUNCTIONS ARE OBTAINED BY SETTING
SWITCH POSITIONS IN A DIP SWITCH BANK
COMPLIES WITH
REQUIREMENTS OF
* IEC STANDARDS
947-4-1 AND 947-5-1
LOW VOLTAGE DIRECTIVE.
WHEN USED
WITH SOCKET
70-465-1
UL Recognized
File No: E43641
* RELEVANT IEC CONTACT UTILIZATION CATEGORIES
THE CLASS 211 TIME DELAY RELAY
MAKES USE OF HYBRID CIRCUITRY,
COMBINING INTEGRATED CIRCUITS
FOR A MULTITUDE OF TIMING
FUNCTIONS, AND THE RELIABILITY
OF RELAY TECHNOLOGY.
AC-1, AC-3, DC-1, AC-15
*1EC = INTERNATIONAL
ELECTROTECHNICAL COMMISSION
(SEE SECTION 11 FOR RELEVANT UTILIZATION CATEGORIES.)
SPECIFICATIONS CLASS 211PROG TDR
OUTLINE DIMENSIONS
Shown in Inches and (Millimeters)
TIMING
Operating Modes Available:
On Delay, Off Delay, One Shot, On & Off Delay
0.1 to 1 Sec, thru 12 to 120 Minutes
Timing Adjustments Available:
Repeatability (repeat Accuracy
when Stabilized):
.
562 (14.2)
±0.1% max. or ± 33 mS AC min., or ± 10 mS DC.
Timing change over tempera-
ture and voltage range:
Timing Tolerance:
± 10%
± 20 %
Reset time:
100 mS Relay On (200 mS max Relay Off)
2.93
(74.4)
CONTACTS
Contact Configuration:
Contact Rating:
DPDT (2 Form C)
10 Amps @ 120VAC/30VDC Resistive
Load, 1/2 Hp @ 240 VAC, 1/3 Hp @ 120 VAC,
NEMA B300 Pilot Duty.
Contact Life:
200,000 Operations @ 120VAC, 10 Amp
resistive Load.
1,000,000 Operations @ 120VAC, 5 Amp
Resistive Load
2,000,000 Operations @ 120VAC, 2 Amps
Resistive Load.
100,000,000 Operations.
2.37
(60.19)
Mechanical Life:
INPUT
Temperature Range (Operate):
- 30 ˚C to + 55˚C
1.75
(44.45)
Temperature Range (Storage): - 40˚C to + 85˚C
Steady State Input Current:
45 mA Max..
PROTECTION
Reverse Polarity:
Transient:
Yes
UL 508 Surge test: 5000V for 50 uS
NEMA ICS2-230 2500VAC
Noise Immunity:
11 PIN OCTAL PLUG-IN
DIELECTRIC STRENGTH
Coil to Contacts:
1500 V rms
1000 V rms
Across Open Contacts:
MECHANICAL
Enclosure:
Polycarbonate dust cover.
Standard 11 Pin Octal
Any
WIRING DIAGRAMS
VIEWED FROM PIN END
Mounting:
Mounting Position:
Weight:
4 oz. (115 grams)
** EXTERNAL CONTROL
SWITCH
●
●
+
NOMINAL
INPUT
VOLTAGE
TIMING
RANGE
PART NUMBER
6
5
7
4
8
▼
▲
▼
▲
24VAC/VDC
-
3
9
ON DELAY, OFF DELAY, ONE SHOT, ON & OFF DELAY
2
10
62 Programmable
Timing Ranges.
1
11
120 VAC, 50/60Hz
24VAC/VDC on Pin 7
W211PROGX-1
INPUT
120VAC 50/60 Hz
PART NUMBERS SHOWN ALSO AVAILABLE THRU STOCKING DISTRIBUTION.
**EXTERNAL CONTROL SWITCH REQUIRED FOR OFF DELAY, ONE SHOT AND
ON & OFF DELAY FUNCTIONS.
To function as a On-Delay timer, a jumper wire must be
connected in place of the external control switch.
EXTERNAL SWITCH SHALL NOT BE CONNECTED TO ANY EXTERNAL LOAD OR
VOLTAGE. DAMAGE TO INTERNAL COMPONENTS CAN OCCUR.
PAGE 117
WEBSITE: www.magnecraft.com EMAIL:info@magnecraft.com FAX ON DEMAND 1-800/891-2957, DOCUMENT 100
