C L A S S
OCTAL 8 & 11 PIN TIME DELAY RELAY
211
CLASS 211
± 0.1 % REPEATABILITY
DPDT, 10 AMP CONTACTS
FIELD ADJUSTABLE TIMING
WHEN USED WITH
SOCKET
70-464-1 (8PIN)
70-465-1 (11 PIN)
UL Recognized
File No: E43641
COMPLIES WITH
REQUIREMENTS OF
* IEC STANDARDS
947-4-1 AND 947-5-1
LOW VOLTAGE DIRECTIVE.
*1EC = INTERNATIONAL
ELECTROTECHNICAL COMMISSION
THE CLASS 211 TIME DELAY RELAY
MAKES USE OF HYBRID CIRCUITRY,
COMBINING INTEGRATED CIRCUITS
FOR A MULTITUDE OF TIMING
* RELEVANT IEC CONTACT UTILIZATION CATEGORIES
AC-1, AC-3, DC-1, AC-15
FUNCTIONS, AND THE RELIABILITY
OF RELAY TECHNOLOGY.
(SEE SECTION 11 FOR RELEVANT UTILIZATION CATEGORIES.)
SPECIFICATIONS CLASS 211 TIME DELAY RELAYS
TIMING
Operating Modes Available:
On Delay, Off Delay
0.1 to 1 Sec, thru 8 to 120 Minutes
Timing Adjustments Available:
Repeatability (repeat Accuracy
when Stabilized):
±0.1% max. or ± 33 mS AC min. or
± 10 mS DC. min.@ Constant voltage
& temperature
Timing change over temperature
and voltage range:
± 10%
- 0 to + 40%
+ 0 to - 40%
100 Milliseconds Max.
Timing Tolerance high end of range:
Timing Tolerance low end of range::
Reset time:
CONTACTS
DPDT (2 Form C)
Contact Configuration::
Contact Rating:
10 Amps @ 120VAC/30VDC Resistive
Load, 1/2 Hp @ 240 VAC, 1/3 Hp @120 VAC, NEMA B300
Pilot Duty.
200,000 Operations @ 120VAC, 10Amp resistive Load.
1,000,000 Operations @ 120 VAC,5 Amp Resistive Load
2,000,000 Operations @ 120VAC, 2 Amps Resistive Load.
50,000,000 Operations.
Contact Life:
Mechanical Life:
INPUT
- 30 ˚C to + 55˚C
- 55˚C to + 85˚C
20 mA @ 120 VAC, 40 mA @ 24 VDC,
20 mA @ 48 VDC 80 mA @ 24 VDC,
15 mA @ 230 VAC, 80 mA @ 12 VDC.
Temperature Range (Operate):
Temperature Range (Storage):
Steady State Input Current:
PROTECTION
Reverse Polarity:
Transient:
DC models only
UL 508 Surge test: 5000V for 50 uS
NEMA ICS2-230 2500 VAC
Noise Immunity:
DIELECTRIC STRENGTH
Coil to Contacts:
1500 V rms
1000 V rms
Across Open Contacts:
MECHANICAL
Enclosure:
Polycarbonate dust cover.
Standard 8 or 11 Pin Octal
Any
Mounting:
Operating Position:
Weight:
4 oz. (115 grams)
