DC CONTROLLED SOLID STATE RELAY
6
CLASS 6
High Transient Capability—Single out-
put features back to back SCR’s an
internal mounted RC (snubber) network
for high dv/dt applications.
Photo-Isolated, Zero Voltage Switching—
Optically coupled for 4000 VAC isolation
between input, output and RFI suppression.
DC CONTROLLED INPUT
WITH L.E.D. "ON" LAMP.
AC SCR OUTPUTS UP
TO 75 AMPS.
NEW!
L.E.D. "ON" LAMP
Recognized to Canadian safety
requirements under the Component
Recognition Program of Underwriters
Laboratories Inc.
UL Recognized
File No. E52197
INPUT CHARACTERISTICS
3 to 32 VDC
Input Impedance
Response Time
400 ohms @ 3 VDC Typical
1/2 Cycle Max.
Maximum Rate of Rise of Off State Voltage dv/dt
200
500 Volts per microsecond
OUTPUT CHARACTERISTICS
120 VAC or 240 VAC
Rated Load Current (Amps rms)
U/L Incandescent Lamp Ampere Ratings
U/L Motor Load Ampere Ratings
Non-Repetitive Surge Current one Cycle (Amps peak)
Maximum rms Overload current for 1 second
Max I2T For Fusing ( t= 8-3ms) A2 sec
Thermal Resistance Junction To Case (TJ , Max.= 1150C) 0c/w
Minimum Load current, (mA).
2.5
2.0
1.0
100
5
72
8.5
50
10
8.0
4.5
100
24
72
1.78
50
25
16
8
250
40
40
30
14
350
80
50
30
14
350
100
75
39
25
1150
150
800 1250 1250 5000
1.02
120 250
0.63 0.63
250
0.63
250
SEE CLASS 6 GENERAL SPECIFICATIONS
INPUT (Over Operating Temperature Range) 0UTPUT (Over Operating Temperature Range)
CROSS REFERENCE TO:
MAX.
MIN.
NOMINAL
PART
NUMBERS
CONTROL
VOLTAGE
RANGE
NAX.
CURRENT
RATING
MAX.
VOLTAGE
POTTER &
BRUMFIELD
CRYDOM
PULL-IN DROPOUT VOLTAGE
VOLTAGE VOLTAGE
IDEC
-
RANGE
1 VDC
1 VDC
1 VDC
1 VDC
1 VDC
1 VDC
3 VDC
3 VDC
3 VDC
3 VDC
3 VDC
3 VDC
2.5 AMPS
10 AMPS
25 AMPS
40 AMPS
50 AMPS
75 AMPS
W6102DSX-1 3-32 VDC
W6110DSX-1 3-32 VDC
W6125DSX-1 3-32 VDC
W6140DSX-1 3-32 VDC
W6150DSX-1 3-32 VDC
W6175DSX-1 3-32 VDC
140 VAC
140 VAC
140 VAC
140 VAC
140VAC
140VAC
D1202
D1210
D1225
D1240
24-120AC
24-120AC
24-120AC
24-120AC
24-120AC
24-120AC
EOM1DA22-4-32
RSSD-10A EOM1DA42-4-32
RSSD-25A
RSSD-40A
RSSD-50A
RSSD-75A
SSR240D25
-
SSR240D50
SSR240D80
1 VDC
1 VDC
1 VDC
1 VDC
1 VDC
1 VDC
3 VDC
3 VDC
3 VDC
3 VDC
3 VDC
3 VDC
2.5 AMPS
10 AMPS
25 AMPS
40 AMPS
50 AMPS
75 AMPS
W6202DSX-1 3-32 VDC
W6210DSX-1 3-32 VDC
W6225DSX-1 3-32 VDC
W6240DSX-1 3-32 VDC
W6250DSX-1 3-32 VDC
W6275DSX-1 3-32 VDC
280 VAC
280 VAC
280 VAC
280 VAC
280 VAC
280 VAC
D2402
D2410
D2425
D2440
D2450
D2475
48-240AC
48-240AC
48-240AC
48-240AC
48-240AC
48-240AC
-
-
RSSD-10A EOM1DA44-4-32
RSSD-25A
RSSD-40A
RSSD-50A
RSSD-75A
SSR240D25
-
SSR240D50
SSR240D80
