C L A S S
DC CONTROLLED INPUT TRIAC OUTPUT SSR
6
High Transient Capability—Single output
features back to back SCR’s and internally
mounted RC (snubber) network for high dv/dt
applications.
Photo-Isolated, Zero Voltage Switching—
Optically coupled for 4000 VAC isolation
between input and output and RFI suppression.
CLASS 6
DC CONTROLLED INPUT
WITH L.E.D. "ON" LAMP.
AC TRIAC OUTPUT.
NEW!
L.E.D. "ON" LAMP
Recognized to Canadian safety
requirements under the Component
Recognition Program of Underwriters
Laboratories Inc.
UL Recognized
File No. E52197
3 to 32 VDC
INPUT CHARACTERISTICS
Input Impedance
Response Time
1500 ohms minimum
1/2 Cycle Max.
Maximum Rate of Rise of Off State Voltage dv/dt
200 Volts per microsecond
120 or 240 VAC
OUTPUT CHARACTERISTICS
10.0
7.0
4.5
100
24
Rated Load Current (Amps rms)
U/L Incandescent Lamp Ampere Ratings
U/L Motor Load Ampere Ratings
Non-Repetitive Surge Current one Cycle (Amps peak)
Maximum rms Overload current for 1 second
Max I2T For Fusing ( t= 8-3ms) A2 sec
42
2.1
Thermal Resistance Junction To Case (TJ , Max.= 1150C) 0c/w
SEE CLASS 6 GENERAL SPECIFICATIONS
INPUT (Over Operating Temperature Range) 0UTPUT (Over Operating Temperature Range)
CROSS REFERENCE TO:
NOMINAL
VOLTAGE
RANGE
MAX.
MIN.
PART
NUMBERS
CONTROL
VOLTAGE
RANGE
MAX.
CURRENT
RATING
MAX.
VOLTAGE
POTTER &
BRUMFIELD
CRYDOM
TD1210
TD2410
PULL-IN DROPOUT
VOLTAGE VOLTAGE
IDEC
1 VDC
3 VDC
10 AMPS
W6110DTX-1 3-32 VDC
140 VAC
280 VAC
24-120AC
-
-
SSRT120D10
SSRT240D10
1 VDC
3 VDC
10 AMPS
W6210DTX-1 3-32 VDC
48-240AC
All current ratings are based on use of suitable thermally conductive compound (e.g. silicone grease between the SSR mounting base and mounting
surface of suitable heat sink).
Part Numbers shown also available thru stocking distribution.
PAGE 104
WEBSITE: www.magnecraft.com - EMAIL:info@magnecraft.com - FAX ON DEMAND 1-800/891-2957 - DOCUMENT 100
