TrueSpeech® Co-Processor
To enable all 4 filters the following command sequence can be used:
Command
5154H
5153H
5155H
5153H
5156H
5153H
5157H
5153H
Status Response
5154H
Action
Select Filter F0
Filter F0 is enabled
Select Filter F1
Filters F1+F0 are enabled
Select Filter F2
Filters F2+F1+F0 are enabled
Select Filter F3
0001H
5155H
0003H
5156H
0007H
5157H
000FH
Filters F3+F2+F1+F0 are enabled
9.20.5
Reading the Filter Energy Output
It is possible to read the actual Filter Energy output values using the following command (516XH):
0101
0001
0110
(7-4)
FILTER
(3-2)
INDEX
(1-0)
(15-12)
(11-8)
FILTER:
INDEX:
00
01
10
11
F0
F1
F2
F3
00
01
10
11
Broadband Energy ls word (bits 15-0)
Broadband Energyms word (bits 31-16)
In Band Energy ls word (bits 15-0)
In Band Energyms word (bits 31-16)
The status response contains the 16-bit value selected by INDEX.
Each filter provides two 32-bit energy parameters:
•
•
The broadband energy of the un-filtered input signal.
The in-band energy at the filter output.
The energy value is calculated over a 240 sample (30ms) input frame:
Energy = 1/32 * ∑ (x/4) * (x/4)
If more than one filter is enabled, the broadband energy from each enabled filter will be the same.
