TrueSpeech® Co-Processor
PRELIMINARY/CONFIDENTIAL
Version: 1.18
Status (S4):
Frequency Factor for Tone 1
(15-0)
TONE INDEX:
Gain1,Gain0:
Frequency Factor:
index in range 1 to 31, index 0 is reserved for a “silent” tone.
level value from tone level table
32767 x cosine(2 x pi x F/8000)
Where pi = 3.14159
F is the desired frequency
8000 is the sample rate at which the CODEC is operating
Note: Single frequencies can be generated by setting either frequency factor to 7FFFH
128
