Virtex-6 FPGA Data Sheet: DC and Switching Characteristics
Table 44: IOB Switching Characteristics for the Commercial (XC) Virtex-6 Devices (Cont’d)
TIOPI
TIOOP
TIOTP
I/O Standard
Speed Grade
Speed Grade
Speed Grade
Units
-3
-2
-1
-1L
-3
-2
-1
-1L
-3
-2
-1
-1L
LVCMOS25, Fast, 24 mA
LVCMOS18, Slow, 2 mA
LVCMOS18, Slow, 4 mA
LVCMOS18, Slow, 6 mA
LVCMOS18, Slow, 8 mA
LVCMOS18, Slow, 12 mA
LVCMOS18, Slow, 16 mA
LVCMOS18, Fast, 2 mA
LVCMOS18, Fast, 4 mA
LVCMOS18, Fast, 6 mA
LVCMOS18, Fast, 8 mA
LVCMOS18, Fast, 12 mA
LVCMOS18, Fast, 16 mA
LVCMOS15, Slow, 2 mA
LVCMOS15, Slow, 4 mA
LVCMOS15, Slow, 6 mA
LVCMOS15, Slow, 8 mA
LVCMOS15, Slow, 12 mA
LVCMOS15, Slow, 16 mA
LVCMOS15, Fast, 2 mA
LVCMOS15, Fast, 4 mA
LVCMOS15, Fast, 6 mA
LVCMOS15, Fast, 8 mA
LVCMOS15, Fast, 12 mA
LVCMOS15, Fast, 16 mA
LVCMOS12, Slow, 2 mA
LVCMOS12, Slow, 4 mA
LVCMOS12, Slow, 6 mA
LVCMOS12, Slow, 8 mA
LVCMOS12, Fast, 2 mA
LVCMOS12, Fast, 4 mA
LVCMOS12, Fast, 6 mA
LVCMOS12, Fast, 8 mA
LVDCI_25
0.51 0.57 0.66 0.70 1.66 1.79 1.99 1.96 1.66 1.79 1.99 1.96
0.55 0.61 0.71 0.73 4.21 4.47 4.87 4.30 4.21 4.47 4.87 4.30
0.55 0.61 0.71 0.73 2.79 2.96 3.21 2.94 2.79 2.96 3.21 2.94
0.55 0.61 0.71 0.73 2.30 2.43 2.64 2.47 2.30 2.43 2.64 2.47
0.55 0.61 0.71 0.73 2.01 2.11 2.27 2.24 2.01 2.11 2.27 2.24
0.55 0.61 0.71 0.73 1.88 1.99 2.15 2.10 1.88 1.99 2.15 2.10
0.55 0.61 0.71 0.73 1.84 1.95 2.11 2.04 1.84 1.95 2.11 2.04
0.55 0.61 0.71 0.73 4.00 4.23 4.57 4.08 4.00 4.23 4.57 4.08
0.55 0.61 0.71 0.73 2.62 2.76 2.97 2.74 2.62 2.76 2.97 2.74
0.55 0.61 0.71 0.73 2.15 2.28 2.46 2.32 2.15 2.28 2.46 2.32
0.55 0.61 0.71 0.73 1.90 1.99 2.13 2.14 1.90 1.99 2.13 2.14
0.55 0.61 0.71 0.73 1.69 1.80 1.97 1.88 1.69 1.80 1.97 1.88
0.55 0.61 0.71 0.73 1.63 1.74 1.91 1.88 1.63 1.74 1.91 1.88
0.64 0.73 0.85 0.85 3.43 3.77 4.29 3.91 3.43 3.77 4.29 3.91
0.64 0.73 0.85 0.85 2.58 2.79 3.10 2.93 2.58 2.79 3.10 2.93
0.64 0.73 0.85 0.85 2.08 2.32 2.68 2.50 2.08 2.32 2.68 2.50
0.64 0.73 0.85 0.85 1.81 1.98 2.23 2.24 1.81 1.98 2.23 2.24
0.64 0.73 0.85 0.85 1.76 1.91 2.13 2.07 1.76 1.91 2.13 2.07
0.64 0.73 0.85 0.85 1.69 1.83 2.04 1.98 1.69 1.83 2.04 1.98
0.64 0.73 0.85 0.85 3.44 3.77 4.28 3.91 3.44 3.77 4.28 3.91
0.64 0.73 0.85 0.85 2.37 2.53 2.78 2.66 2.37 2.53 2.78 2.66
0.64 0.73 0.85 0.85 1.80 2.05 2.42 2.16 1.80 2.05 2.42 2.16
0.64 0.73 0.85 0.85 1.76 1.90 2.11 2.04 1.76 1.90 2.11 2.04
0.64 0.73 0.85 0.85 1.64 1.77 1.97 1.90 1.64 1.77 1.97 1.90
0.64 0.73 0.85 0.85 1.62 1.76 1.96 1.92 1.62 1.76 1.96 1.92
0.72 0.81 0.93 0.95 3.14 3.39 3.75 3.54 3.14 3.39 3.75 3.54
0.72 0.81 0.93 0.95 2.43 2.63 2.93 2.79 2.43 2.63 2.93 2.79
0.72 0.81 0.93 0.95 1.92 2.11 2.41 2.26 1.92 2.11 2.41 2.26
0.72 0.81 0.93 0.95 1.87 2.02 2.25 2.17 1.87 2.02 2.25 2.17
0.72 0.81 0.93 0.95 2.71 2.98 3.39 3.11 2.71 2.98 3.39 3.11
0.72 0.81 0.93 0.95 1.93 2.16 2.51 2.31 1.93 2.16 2.51 2.31
0.72 0.81 0.93 0.95 1.75 1.89 2.11 2.05 1.75 1.89 2.11 2.05
0.72 0.81 0.93 0.95 1.69 1.82 2.02 1.98 1.69 1.82 2.02 1.98
0.51 0.57 0.66 0.70 2.05 2.14 2.26 2.26 2.05 2.14 2.26 2.26
0.55 0.61 0.71 0.73 2.07 2.23 2.47 2.38 2.07 2.23 2.47 2.38
0.64 0.73 0.85 0.85 1.85 2.01 2.24 2.18 1.85 2.01 2.24 2.18
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
LVDCI_18
LVDCI_15
DS152 (v3.6) March 18, 2014
www.xilinx.com
Product Specification
29
