Pre-Production
WM8959
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
R56 (38h)
5
DIS_LLINE
0b
Discharges LOP and LON outputs via
approx 500Ω resistor
Anti-Pop (1)
0 = Not active
1 = Actively discharging LOP and LON
4
3
2
1
0
DIS_RLINE
DIS_OUT3
DIS_OUT4
DIS_LOUT
DIS_ROUT
0b
0b
0b
0b
0b
Discharges ROP and RON outputs via
approx 500Ω resistor
0 = Not active
1 = Actively discharging ROP and RON
Discharges OUT3 output via approx 500Ω
resistor
0 = Not active
1 = Actively discharging OUT3
Discharges OUT4 output via approx 500Ω
resistor
0 = Not active
1 = Actively discharging OUT4
Discharges LOUT output via approx 500Ω
resistor
0 = Not active
1 = Actively discharging LOUT
Discharges ROUT output via approx 500Ω
resistor
0 = Not active
1 = Actively discharging ROUT
Table 76 Output Discharge Control
VMID REFERENCE DISCHARGE CONTROL
The VMID reference can be discharged to AGND through internal resistors. Discharging VMID
ensures that a subsequent start-up procedure commences with a known voltage condition; this is
necessary in order to ensure maximum suppression of audible pops associated with start-up. VMID
is discharged by setting VMIDTOG, as described in Table 77.
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
R57 (39h)
0
VMIDTOG
0b
Connects VMID to ground
0 = Disabled
Anti-Pop (2)
1 = Enabled
Table 77 VMID Reference Discharge Control
PP, May 2008, Rev 3.1
121
