WM8352
Production Data
REFER TO
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
R36 (24h)
Under
Voltage
Interrupt
status Mask
11
IM_UV_LDO4_EINT
0
Interrupt mask.
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
10
9
IM_UV_LDO3_EINT
IM_UV_LDO2_EINT
IM_UV_LDO1_EINT
IM_UV_DC6_EINT
IM_UV_DC5_EINT
IM_UV_DC4_EINT
IM_UV_DC3_EINT
IM_UV_DC2_EINT
IM_UV_DC1_EINT
0
0
0
0
0
0
0
0
0
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
8
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
5
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
4
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
3
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
2
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
1
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Interrupt mask.
0
0 = Do not mask interrupt.
1 = Mask interrupt.
Reset by state machine.
Register 24h Under Voltage Interrupt status Mask
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R37 (25h)
Over Current
Interrupt
15
IM_OC_LS_EINT
0
Interrupt mask.
0 = Do not mask interrupt.
1 = Mask interrupt.
status Mask
Reset by state machine.
Register 25h Over Current Interrupt status Mask
PD, February 2011, Rev 4.4
