Production Data
WM8352
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
Overcurrent interrupt.
REFER TO
R29 (1Dh)
Over Current
Interrupt
15
OC_LS_EINT
0
(Rising Edge triggered)
Note: This bit is cleared once read.
status
Register 1Dh Over Current Interrupt status
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R30 (1Eh)
GPIO
Interrupt
Status
12
GP12_EINT
0
GPIO12 interrupt.
(Trigger controlled by GP12 registers.)
Note: This bit is cleared once read.
GPIO11 interrupt.
11
10
9
GP11_EINT
GP10_EINT
GP9_EINT
GP8_EINT
GP7_EINT
GP6_EINT
GP5_EINT
GP4_EINT
GP3_EINT
GP2_EINT
GP1_EINT
GP0_EINT
0
0
0
0
0
0
0
0
0
0
0
0
(Trigger controlled by GP11 registers.)
Note: This bit is cleared once read.
GPIO10 interrupt.
(Trigger controlled by GP10 registers.)
Note: This bit is cleared once read.
GPIO9 interrupt.
(Trigger controlled by GP9 registers.)
Note: This bit is cleared once read.
GPIO8 interrupt.
8
(Trigger controlled by GP8 registers.)
Note: This bit is cleared once read.
GPIO7 interrupt.
7
(Trigger controlled by GP7 registers.)
Note: This bit is cleared once read.
GPIO6 interrupt.
6
(Trigger controlled by GP6 registers.)
Note: This bit is cleared once read.
GPIO5 interrupt.
5
(Trigger controlled by GP5 registers.)
Note: This bit is cleared once read.
GPIO4 interrupt.
4
(Trigger controlled by GP4 registers.)
Note: This bit is cleared once read.
GPIO3interrupt.
3
(Trigger controlled by GP3 registers.)
Note: This bit is cleared once read.
GPIO2 interrupt.
2
(Trigger controlled by GP2 registers.)
Note: This bit is cleared once read.
GPIO1 interrupt.
1
(Trigger controlled by GP1 registers.)
Note: This bit is cleared once read.
GPIO0 interrupt.
0
(Trigger controlled by GP0 registers.)
Note: This bit is cleared once read.
Register 1Eh GPIO Interrupt Status
PD, February 2011, Rev 4.4
235
