Production Data
WM8352
SUPPLY
REGISTER SETTING
DC1_ENSLOT [3:0] = 0010
DC1_VSEL [6:0] = 000_1110
DC2_ENSLOT [3:0] = 0000
DESCRIPTION
Timeslot 2
1.2V
DCDC1
DCDC2
DCDC3
DCDC4
DCDC5
DCDC6
LDO1
Disabled
DC3_ENSLOT [3:0] = 0110
DC3_VSEL [6:0] = 010_0110
DC4_ENSLOT [3:0] = 0100
DC4_VSEL [6:0] = 000_1110
DC5_ENSLOT [3:0] = 0000
Timeslot 6
3.0V
Timeslot 4
1.2V
Disabled
DC6_ENSLOT [3:0] = 0011
DC6_VSEL [6:0] = 010_0110
LDO1_ENSLOT [3:0] = 0000
LDO1_VSEL [4:0] = 1_1100
LDO2_ENSLOT [3:0] = 0001
LDO2_VSEL [4:0] = 0_0110
LDO3_ENSLOT [3:0] = 0101
LDO3_VSEL [4:0] =1_1100
LDO4_ENSLOT [3:0] = 0000
LDO4_VSEL [4:0] = 1_1010
Timeslot 3
1.8V
Disabled
3.0V
LDO2
Timeslot 1
1.2V
LDO3
Timeslot 5
3.0V
LDO4
Disabled
2.8V
Table 67 Default Supply Voltages / Power-up Sequence for Configuration Mode 10
Start
Up
Time
Slot1
Time
Slot2
Time
Slot3
Time
Slot4
Time
Slot5
Time
Slot6
The time delay between each time slot is approximately 1.28ms.
DCDC1
DCDC2
DCDC3
DCDC4
DCDC5
DCDC6
LDO1
Disabled at
start-up
Disabled at
start-up
Disabled at
start-up
LDO2
LDO3
Disabled at
start-up
LDO4
Figure 67 Power-up Sequence - Configuration Mode 10
PD, February 2011, Rev 4.4
121
