W90N745CD/W90N745CDG
PWM Control Register (PWM_PCR)
REGISTER
PWM_PCR
ADDRESS
R/W
DESCRIPTION
RESET VALUE
0xFFF8_7008 R/W PWM Control Register
0x0000_0000
31
23
15
30
22
14
29
21
13
28
20
12
27
19
26
18
25
17
24
16
Reserved
Reserved
PCR19
11
PCR18
10
PCR17
9
PCR16
8
PCR15
7
PCR14
6
PCR13
5
PCR12
4
PCR11
3
PCR10
2
PCR09
1
PCR08
0
PCR07
PCR06
PCR 19
PCR05
PCR04
PCR03
PCR02
PCR01
PCR00
BITS
DESCRIPTIONS
Channel 3 toggle/one shot mode
1 = toggle mode
[19]
0 = one shot mode
Channel 3 Inverter on/off
1 = inverter on
[18]
[17]
[16]
PCR 18
PCR 17
PCR 16
0 = inverter off
Reserved
Channel 3 enable/disable
1 = enable
0 = disable
Channel 2 toggle/one shot mode
1 = toggle mode
[15]
PCR 15
0 = one shot mode
Channel 2 Inverter on/off
1 = inverter on
[14]
[13]
PCR 14
PCR 13
0 = inverter off
Reserved
