W90N745CD/W90N745CDG
PWM Prescaler Register (PWM_PPR)
REGISTER
PWM_PPR
ADDRESS
R/W
DESCRIPTION
RESET VALUE
0xFFF8_7000 R/W PWM Prescaler Register
0x0000_0000
31
23
15
7
30
22
14
6
29
21
13
5
28
20
12
4
27
19
11
3
26
18
10
2
25
17
9
24
16
8
DZI1
DZI0
CP1
CP0
1
0
BITS
DESCRIPTIONS
DZI1: Dead zone interval register 1, these 8-bit determine dead zone
length.
[31:24]
DZI1
DZI0
CP1
The 1 unit time of dead zone length is received from clock selector 2.
DZI0: Dead zone interval register 0, these 8-bit determine dead zone
length.
[23:16]
[15:8]
The 1 unit time of dead zone length is received from clock selector 0.
CP1 : Clock prescaler 1 for PWM Timer channel 2 & 3
Clock input is divided by (CP1 + 1) before it is fed to the counter. 2 & 3
If CP1=0, then the prescaler 1 output clock will be stopped.
CP0 : Clock prescaler 0 for PWM Timer channel 0 & 1
Clock input is divided by (CP0 + 1) before it is fed to the counter. 0 & 1
If CP0=0, then the prescaler 0 output clock will be stopped.
[7:0]
CP0
