W90N745CD/W90N745CDG
BITS
[31]
DESCRIPTIONS
Reserved
Endpoint A type
00: reserved
01: bulk
[30:29]
EPA_TYPE
EPA_DIR
10: interrupt
11: isochronous
Endpoint A direction
0: OUT
[28]
1: IN
[27:26]
[25:16]
[15:12]
[11:8]
[7:4]
Reserved
EPA_MPS
EPA_ALT
EPA_INF
EPA_CFG
EPA_NUM
Endpoint A max. packet size
Endpoint A alternative setting (READ ONLY)
Endpoint A interface
Endpoint A configuration
[3:0]
Endpoint A number
USB Endpoint A Control Register (EPA_CTL)
REGISTER
ADDRESS
R/W
DESCRIPTION
RESET VALUE
EPA_CTL
0xFFF0604C
R/W
USB endpoint A control register
0x0000_0000
31
23
30
22
29
21
28
Reserved
20
Reserved
12
Reserved
27
19
26
18
25
24
16
17
9
15
14
6
13
5
11
3
10
2
8
0
7
4
1
EPA_STL_CLR
Reserved EPA_ZERO
EPA_THRE EPA_STL EPA_RDY EPA_RST EPA_EN
