W25Q16DV
8. ELECTRICAL CHARACTERISTICS
(1)
8.1 Absolute Maximum Ratings
PARAMETERS
SYMBOL
VCC
CONDITIONS
RANGE
UNIT
Supply Voltage
–0.6 to +4.6
V
V
Voltage Applied to Any Pin
VIO
Relative to Ground
–0.6 to VCC+0.4
<20nS Transient
Relative to Ground
Transient Voltage on any Pin
VIOT
–2.0V to VCC+2.0V
V
Storage Temperature
TSTG
TLEAD
VESD
–65 to +150
See Note (2)
°C
°C
V
Lead Temperature
Electrostatic Discharge Voltage
Human Body Model(3) –2000 to +2000
Notes:
1. This device has been designed and tested for the specified operation ranges. Proper operation outside
of these levels is not guaranteed. Exposure to absolute maximum ratings may affect device reliability.
Exposure beyond absolute maximum ratings may cause permanent damage.
2. Compliant with JEDEC Standard J-STD-20C for small body Sn-Pb or Pb-free (Green) assembly and the
European directive on restrictions on hazardous substances (RoHS) 2002/95/EU.
3. JEDEC Std JESD22-A114A (C1=100pF, R1=1500 ohms, R2=500 ohms).
8.2 Operating Ranges
SPEC
PARAMETER
SYMBOL CONDITIONS
UNIT
MIN
MAX
FR = 80MHz,
VCC
fR = 50MHz
FR = 104MHz, fR = 50MHz
2.7
3.0
3.0
3.6
Supply Voltage
V
Ambient Temperature,
Operating
TA
Industrial
-40
+85
°C
