Case outline U.
Symbol
Millimeters
Inches
Min
Min
Max
6.22
0.89
0.51
1.40
30.48
Max
.245
.035
.020
.055
1.200
A
A1
5.08
0.64
.200
.025
øb
0.41
.016
øb1
D/E
D1/E1
D2
1.14
.045
29.72
1.170
25.40 TYP
1.000 TYP
15.24 TYP
2.54 TYP
.600 TYP
.100 TYP
e
L
3.68
3.94
.145
.155
NOTES:
1.The U.S. preferred system of measurement is the metric SI. This item was designed using inch-pound units of
measurement. In case of problems involving conflicts between the metric and inch-pound units, the inch-pound
units shall rule.
2.Pin numbers are for reference only.
FIGURE 1. Case outline(s) - Continued.
SIZE
STANDARD
MICROCIRCUIT DRAWING
5962-94611
A
REVISION LEVEL
SHEET
DEFENSE SUPPLY CENTER COLUMBUS
COLUMBUS, OHIO 43216-5000
17
R
DSCC FORM 2234
APR 97
