SFH617A
Optocoupler, Phototransistor Output,
High Reliability, 5300 VRMS, 110 °C Rated
Vishay Semiconductors
PACKAGE DIMENSIONS in inches (millimeters)
2
1
Pin one ID
0.255 (6.48)
0.268 (6.81)
ISO method A
3
4
0.179 (4.55)
0.190 (4.83)
0.300 (7.62) typ.
0.031 (0.79) typ.
0.050 (1.27) typ.
0.030 (0.76)
0.045 (1.14)
0.130 (3.30)
0.150 (3.81)
0.230 (5.84)
0.250 (6.35)
10°
4°
typ.
0.110 (2.79)
0.130 (3.30)
0.020 (0.508)
0.035 (0.89)
3° to 9°
0.008 (0.20)
0.018 (0.46)
0.050 (1.27)
0.100 (2.54)
0.012 (0.30)
0.022 (0.56)
i178027
Option 6
Option 9
Option 7
0.375 (9.53)
0.395 (10.03 )
0.300(7.62)
typ.
0.407(10.36)
0.391(9.96)
0.307(7.8)
0.291(7.4)
0.300 (7.62)
ref.
0.028 (0.7)
min.
0.180(4.6)
0.160(4.1)
0.0040 (0.102)
0.012 (0.30 ) typ.
0.0098 (0.249)
0.315(8.0)
min.
0.020 (0.51)
0.040 (1.02)
0.014(0.35)
0.010(0.25)
0.331(8.4)
15° max.
min.
0.315 (8.00)
0.400(10.16)
0.430(10.92)
min.
0.406(10.3)
max.
