9.2.2 DC Characteristics
DC characteristics contain the spread of values guaranteed within the specified supply voltage range
unless otherwise specified. Typical values represent the average value of all parts measured at +25 C.
°
Temperature variation also causes stray to some values. A device with typical values will not leave Min/Max
range within the full temperature range.
Parameter
Symbol
VINL
Condition
Min Typ Max Unit
Input voltage low level
Input voltage high level
Input with pull-down
Input with pull-up
VCCIO = 3.3V
VCCIO = 3.3V
VIN = 3.3V
VIN = 0V
-0.3
2.3
5
0.8
3.6
110
-5
V
V
VINH
30
µA
µA
µA
µA
V
-110 -30
Input low current
VIN = 0V
-10
-10
0.4
2.64
4
10
Input high current
VIN = VCCIO
VCCIO = 3.3V
VCCIO = 3.3V
10
Output voltage low level
Output voltage high level
Output driver strength standard
Input impedance of Analog Input
VOUTL
VOUTH
IOUT_DRV
R_ADC
V
mA
kΩ
TJ = 25°C
85
100 115
Table 25: DC Characteristics
All I/O lines include Schmitt-Trigger inputs to enhance noise margin.
