(Note 1)
Qꢀ
Product Groups with a 3-V Supply
Power-saving modes
CEC controller
USB-Host
High-resolution PPG
M320 Group
M340 Group
M330 Group
O
O
O
Features
Features
Features
USB host controller
System solutions that combine a MCU and an
audio DSP
Application examples
Car and home audio systems
High-accuracy analog control interface
Small package (6 x 6 mm TFBGA113)
High-resolution PPG ideal for motor control
Application examples
Dedicated controller compliant with HDMI 1.3a (CEC)
Remote control signal preprocessor essential for
digital consumer electronics
O
O
O
Application examples
DVCs, DSLR cameras, camera lens controllers
Digital TVs, projectors, Blu-ray recorders,
AV systems, printers, home appliances,
factory equipment, office equipment
Multiple serial interfaces
1.8-V operation
M360 Group
M390 Group
O
O
Features
Large-capacity Flash memory
Features
Power-saving modes for 1.8-V operation
High-speed on-chip oscillator
Small package (6 x 6 mm TFBGA120)
Application examples
Power supply monitors, battery-operated devices,
remote-controlled equipment, game consoles,
AV systems
Up to 7 communications interfaces
(SIO, I2C, SPI, UART, CAN, USB, EtherMAC)
Programmable Motor Driver (PMD)
Multi-purpose timer capable of IGBT control
Small package (9 x 9 mm TFBGA109)
Application examples
Printers, AV systems, digital appliances,
PC peripherals, industrial equipment,
networking equipment, office equipment
Qꢀ
O
Automotive Applications
O
M350 Group
Automotive Applications
M350
O
Features
Programmable Motor Driver (PMD), CAN
controllers, timers, 12-bit AD converter, crossbar
switches, functional safety capabilities and 5-V I/Os
Application examples
(Note 1)
Qꢀ
Product Groups with a 5-V Supply
O
Electric power steering (EPS) systems and other
automotive applications
Multi-purpose timers
for IGBT control
M380 Group
M370 Group
On-chip vector engine
O
O
Features
Features
M354
Multi-purpose timers for motor and IGBT control
Single 5-V supply operation with high market
demands
System solutions that combine an MCU with
various peripheral ICs
Application examples
Air conditioners, refrigerators, electric oven-grills,
rice cookers, induction cooktops
Toshiba-original vector engine (VE)
Single 5-V supply operation with high market
demands
System solutions that combine an MCU with motor
drivers
Small package (7 x 7 mm LQFP48)
Application examples
Washing machines, air conditioners, refrigerators,
heat pumps, inverter-motor-controlled equipment
O
Features
Advanced PMD (A-PMD), VE, CAN controllers,
timers, 12-bit AD converters, resolver-to-digital
converter, crossbar switches, functional safety
capabilities and 5-V I/O
Application examples
HEV, EV and other automotive applications
O
O
O
Qꢀ
TX03 Series Common Functions
Oꢀ
CortexTM-M3 core
ETM (embedded trace macro cell)
Oꢀ
Except some microcontrollers in the M370 Group
High-speed writing by NANO-FlashTM technology
Oꢀ
Oꢀ
Oꢀ
Watchdog timer
On-chip debug function
(Note 1)
Qꢀ
Added Functions
M320
M330
M340
M350
M360
M370
M380
M390
Group
Group
Group
Group
Group
Group
Group
Group
High-speed operating clock (80 MHz or higher)
Large-capacity Flash ROM (1 MB or more)
On-chip DRAM
USB device/host
CAN
EtherMAC
(Note 4)
Motor control
Vector Engine
Low-voltage operation (1.8 V or higher)
Single 5-V power supply
High-accuracy analog IP (Note 2)
Functions for audiovisual and home appliances(Note 3)
Compact package(Note 5)
External bus interface
JTAG boundary scan
Note 1: There are microcontrollers that do not contain some of the peripherals shown. For details, see appropriate datasheets.
Note 2: Contains either analog circuitry for motor control or a 12-bit AD converter.
Note 3: Contains a Consumer Electronics Control (CEC) unit, a remote control signal preprocessor or an I2S interface.
Note 4: Ultrasonic motor controller
Note 5: 9 x 9 mm or smaller packages
–
–
