M390 Group
The 1.8-V low-power mode of the M390 Group makes it ideal for battery-operated applications. The on-chip high-speed,
high-accuracy oscillator helps reduce product costs. The M390 Group are available in standard and small packages.
Qꢀ
Qꢀ
Features
Application
High-performance ARM CortexTM-M3 core: 20-MHz operation (max)
Toshiba-original NANO FLASHTM memory: Fast programming
1.8-V low-power (RTC) mode (1.3 +A typ.)
Health care equipment
Game consoles
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
Oꢀ
AV systems
Various serial interfaces
Power monitoring devices
Battery-operated devices
Remote-controlled equipment
CEC interface and remote control signal preprocessor that remain active even in
low-power mode
Oꢀ
Oꢀ
Oꢀ
On-chip high-speed oscillator (9.91 MHz 3ꢁ @ 0 to 70ꢀC)
Oscillation frequency detection (OFD); compliant with the IEC 60730 standard
Small package (6 x 6 mm TFBGA120) Note: TMPM395FWAXBG only
Qꢀ
System Block Diagram (Digital Video Camera)
System control unit
Audio Video
Input unit
Memory Card
USB
Signal
Processor
for DVC
Camera
DSP
LENS
Analog Front End
IEEE 1394 In-out
Display section
LCD panel
LCDC
Zoom
Motor
Motor
Drive
OPAMP
DECK
System
EEPROM
Microcontroller
TMPM395
TMPM390
The video camera unit and the video recorder
unit are controlled by a single chip microcontroller.
Key
Large-scale software to control
the camera unit and the recorder
unit is contained. System control
interface (high-pin count), high
performance and low-power
consumption.
CEC
HDMI Out
Flash
HDMI Tx
Qꢀ
Low-Power MCUs
Audiovisual systems must be able to receive Consumer Electronics Control (CEC) commands and remote control signals even when they are off.
While the predecessor microcontrollers, the TLCS-900/L1 and TLCS-870/C Series, need to keep these functions in normal operating mode even
when off, the M390 Group of microcontrollers can do them in low-power mode at 32.768 kHz, significantly reducing standby power consumption.
MCU Power Consumption When an AV System is in Standby Mode
Significant Reduction of Standby Power
80
72.5 mW
(When CEC and remote control
signal preprocessor are active)
70
60
Reduces standby
power to as low
as 0.14 mW.
Reduced to
1/518
50
43 mW
40
30
20
10
0
Zzz...
SLEEP Mode
Features
0.14 mW
Returns to Normal
mode on reception of
CEC/remote control
signals.
Reduced to
1/307
TMP89FM42UG TMP91FW27UG TMPM390FWFG
Qꢀ
Product Lineup
ROM (Flash)
Size
RAM
Size
Part Number
Package
128 KB
128 KB
8 KB
8 KB
LQFP100 (14 x 14 mm)
TFBGA120 (6 x 6 mm)
1.8-V low-power (RTC) mode (1.3 +A typ.)
TMPM390FWFG **
TMPM395FWAXBG
Housed in a small package.
1.8-V low-power (RTC) mode (1.3 +A typ.)
**: Under development
–
–
