SN65HVD230
SN65HVD231
SN65HVD232
www.ti.com
SLOS346H–MARCH 2001–REVISED JULY 2006
ABSOLUTE MAXIMUM RATINGS
over operating free-air temperature range (unless otherwise noted)(1)(2)
UNIT
-0.3 V to 6 V
-4 V to 16 V
-25 V to 25 V
-0.5 V to VCC + 0.5 V
±11 mA
Supply voltage range, VCC
Voltage range at any bus terminal (CANH or CANL)
Voltage input range, transient pulse, CANH and CANL, through 100 Ω (see Figure 7)
Input voltage range, VI (D or R)
Receiver output current, IO
CANH, CANL and GND
Human body model(3)
16 kV
Electrostatic discharge
All Pins
All pins
4 kV
Charged-device model(4)
1 kV
Continuous total power dissipation
See Dissipation Rating Table
(1) Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under "recommended operating
conditions" is not implied. Exposure to absolute-maximum-rated conditions for extended periods amy affect device reliability.
(2) All voltage values, except differential I/O bus voltages, are with respect to network ground terminal.
(3) Tested in accordance with JEDEC Standard 22, Test Method A114-A.
(4) Tested in accordance with JEDEC Standard 22, Test Method C101.
DISSIPATION RATING TABLE
T
A ≤ 25°C
DERATING FACTOR(1)
ABOVE TA = 25°C
TA = 70°C
POWER RATING
TA = 85°C
POWER RATING
PACKAGE
POWER RATING
D
725 mW
5.8 mW/°C
464 mW
377 mW
(1) This is the inverse of the junction-to-ambient thermal resistance when board-mounted and with no air flow.
RECOMMENDED OPERATING CONDITIONS
MIN NOM MAX UNIT
Supply voltage, VCC
3
-2(1)
-2.5
2
3.6
7
V
V
V
V
V
V
V
V
Voltage at any bus terminal (common mode) VIC
Voltage at any bus terminal (separately) VI
7.5
High-level input voltage, VIH
D, R
D, R
Low-level input voltage, VIL
0.8
6
Differential input voltage, VID (see Figure 5)
Input voltage, V(Rs)
-6
0
VCC
VCC
Input voltage for standby or sleep, V(Rs)
Wave-shaping resistance, Rs
0.75 VCC
0
-40
-8
100 kΩ
Driver
High-level output current, IOH
mA
Receiver
Driver
48
mA
8
Low-level output current, IOL
Receiver
Operating free-air temperature, TA
-40
85 °C
(1) The algebraic convention, in which the least positive (most negative) limit is designated as minimum is used in this data sheet.
