表 5-1. Pin Functions (continued)
PIN
I/O
DESCRIPTION
NO.
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
NAME
NC
̶
No Connection
OUTE1
OUTE0
NC
O
O
̶
Current output channel E1
Current output channel E0
No Connection
OUTD1
OUTD0
NC
O
O
̶
Current output channel D1
Current output channel D0
No Connection
OUTC1
OUTC0
NC
O
O
̶
Current output channel C1
Current output channel C0
No Connection
OUTB1
OUTB0
OUTA1
OUTA0
ADDR0
ADDR1
ADDR2
ADDR3
O
O
O
O
I
Current output channel B1
Current output channel B0
Current output channel A1
Current output channel A0
Device address setting (Bit0)
Device address setting (Bit1)
Device address setting (Bit2)
Device address setting (Bit3)
I
I
I
